型号 MODEL |
BL662D |
BL661D |
BL-660D |
|
成像器件 Pick-up Device |
1/3 “ SONY Supper HAD CCD |
1/4 “ SONY Supper HAD CCD |
|
感觉面积 Scanning Area |
4.9mm(H) x 3.7mm(v) |
3.6mm(H) x 2.7mm(v) |
|
图像像素 Picture Element |
PAL:752 (H)x582(V) NTSC:768(H)x494(V) |
PAL:500 (H)x582(V)NTSC:510(H)x492(V) |
|
电视系统 TV System |
PAL / NTSC |
|
水平解析度Horizontal Resolution |
540TV Lines |
420TV Lines |
|
最低照度 Minimum Illumination |
IR ON 0Lux |
|
信噪比 S/N Ratio |
More than 48dB |
|
自动电子快门AutoElectronicShutter |
PAL:1/50s-1/100,000s NTSC:1/60s-1/100,000s |
|
伽玛校正 Gamma Characteristic |
0.45 |
|
增益控制Auto Gain Control |
Auto |
|
白平衡 Auto White Balance |
Auto |
|
背光补偿Back Light Compensation |
Auto |
|
同步系统 Synchronous System |
Internal Synchronization |
|
镜头安装 Lens Mount |
Board Lens:6/8/12mm |
|
视频输出 Video Output |
1.0Vp-p, 75Ω，BNC Connector |
|
红外灯距离InfraredLampsIrradiationDistance |
40M |
|
防护等级Protection Rate |
IP66 |
|
电源 Power Supply |
DC 12V 土10% |
|
耗电流Power Consumpiton |
150mA(IR ON MAX450mA) |
110mA(IR ON MAX 400mA) |
|
工作温度Operating Temperature |
-10℃～＋50℃ |
|
尺寸Dimensions(W x D x H) |
φ61 x 115mm |
|
重量Weight(g) |
520g |
|
材质Material |
铝合金Aluminum alloy |
